HOT Topic : Hi-Tni LCD collections for outdoor applications

: Category: Products

Features

From 4.3" to 55" full range TFT
Applied 90~110C Hi-Tni LC for outdoor applications
TTL / LVDS / EDP interface
Resolution support: QVGA / VGA / WVGA / SVGA / WSVGA / XGA / WXGA / SXGA / HD / FHD
Complete display kits solutions:
extra wide temperature AD board,
extra wide temperature LED driver board,
auto brightness control kits,
auto temperature control kits
Computing solutions

Size	AGL Model	Brightness (nit)	Resolution	View angle (Deg)	Contrast ratio	Interface	OP Temp (℃)	features
4.3"(16:9)	VM04B1 VB	1000	480x272	170 / 170	800:1	TTL	80 / -30	IPS
5.0"(16:9)	VM05B1 VC	1000	800x480	160 / 160	1000:1	RGB	80 /-30	IPS
5.0"(16:9)	VM05B1 VD	1000	800x480	160 / 160	1000:1	LVDS	80 /-30	IPS
5.7"(4:3)	VM06B2 V5	1000	640x480	176 / 176	800:1	TTL	85 / -30	40 piin
5.7"(4:3)	VM06B2 V6	1600	640x480	176 / 176	800:1	TTL	85 / -30	40 piin
5.7"(4:3)	VM06B2 VN	550	640x480	160 / 140	800:1	Digital	85 / -30
5.7"(4:3)	VM06B2 VA	1200	640x480	160 / 140	800:1	Digital	85 / -30
5.7"(4:3)	VM06B2 VB	1600	640x480	160 / 140	800:1	Digital	85 / -30
6.5"(4:3)	VM06B4 V1	1200	640x480	160 / 140	600:1	LVDS	85 / -30
7"(16:9)	VM07B1 V1	1000	800x480	140 / 120	500:1	Digital	85 / -30
7"(16:9)	VM07B1 V2	500	800x480	140 / 120	500:1	Digital	85 / -30
7"(16:9)	VM07B1 V3	1200	800x480	140 / 120	500:1	Digital	85 / -30
7"(16:9)	VM07B1 V4	2000	800x480	140 / 120	500:1	Digital	85 / -30
7"(16:9)	VM07B1 VA	1000	800x480	140 / 120	500:1	LVDS	85 / -30	Driver built-in
7"(16:9)	VM07B1 VB	500	800x480	140 / 120	500:1	LVDS	85 / -30	Driver built-in
7"(16:9)	VM07B4 V1	1000	800x480	140 / 120	500:1	Digital	85 / -30	Square pixel
7"(16:9)	VM07B4 V2	500	800x480	140 / 120	500:1	Digital	85 / -30	Square pixel
7"(16:9)	VM07B4 V3	1000	800x480	140 / 120	600:1	LVDS	85 / -30	Square pixel
7"(16:9)	VM07B4 VN	500	800x480	178 / 178	800:1	LVDS	85 / -30	Square pixel
7"(16:9)	VM07B4 VA	1000	800x480	178 / 178	800:1	LVDS	85 / -30	Square pixel
7"(16:9)	VM07B4 VB	2000	800x480	178 / 178	800:1	LVDS	85 / -30	Square pixel
7"(16:9)	VM07B4 VE	1000	800x480	176 / 176	1000:1	RGB	85 / -30	40pin
8"(16:9)	VM08B4 V1	1600	800x480	140 / 120	500:1	LVDS	85 / -30
8"(16:9)	VM08B4 V2	2000	800x480	140 / 120	500:1	LVDS	85 / -30
8"(16:9)	VM08B4 V3	1000	800x480	140 / 120	500:1	LVDS	85 / -30
8"(16:9)	VM08B4 V4	500	800x480	140 / 120	500:1	LVDS	85 / -30
8"(16:9)	VM08B4 VA	1600	800x480	140 / 120	500:1	Digital	85 / -30
8"(16:9)	VM08B4 VB	2000	800x480	140 / 120	500:1	Digital	85 / -30
8"(16:9)	VM08B4 VC	1000	800x480	140 / 120	500:1	Digital	85 / -30
8"(16:9)	VM08B4 VD	500	800x480	140 / 120	500:1	Digital	85 / -30
8.4"(4:3)	VM08B2 V0	450	800x600	160 / 140	600:1	LVDS	80 / -30
8.4"(4:3)	VM08B2 V2	1000	800x600	160 / 140	600:1	LVDS	85 / -30
8.4"(4:3)	VM08B2 V3	1600	800x600	160 / 140	600:1	LVDS	85 / -30
8.4"(4:3)	VM08BC V0	600	1024x768	176 / 176	1000:1	LVDS	85 / -30
8.4"(4:3)	VM08BC V1	1200	1024x768	176 / 176	1000:1	LVDS	85 / -30
8.4"(4:3)	VM08BC V2	1600	1024x768	176 / 176	1000:1	LVDS	85 / -30
10.1"(16:9)	VM10B3 V0	500	1280x800	176 / 176	800:1	LVDS	80 / -30
10.1"(16:9)	VM10B3 V1	1200	1280x800	176 / 176	800:1	LVDS	80 / -30
10.1"(16:9)	VM10B3 V2	2200	1280x800	176 / 176	800:1	LVDS	80 / -30
10.1"(16:9)	VM10B3 V3	1600	1280x800	176 / 176	800:1	LVDS	80 / -30
10.1"(16:9)	VM10B8 V1	1000	1024x600	160 / 160	500:1	LVDS	80 / -30
10.1"(16:9)	VM10B8 VZ	500	1024x600	160 / 160	500:1	LVDS	80 / -30
10.1"(16:9)	VM10BC V1	1000	1280x720	170 / 170	1000:1	LVDS	85 / -30
10.1"(16:9)	VM10BC V2	2000	1280x720	170 / 170	1000:1	LVDS	85 / -30
10.2"(16:9)	VM10B2 V1	850	800x480	130 / 110	300:1	Digital	85 / -30
10.2"(16:9)	VM10B2 V4	550	800x480	130 / 110	300:1	Digital	85 / -30
10.3 EW	VM10S1 V0	800	1920x720	170 / 170	1300:1	LVDS	85 / -30
10.3 EW	VM10S1 V1	1500	1920x720	170 / 170	1300:1	LVDS	85 / -30
10.4"(4:3)	VM10B4 V0	400	800x600	140 / 160	700:1	LVDS	85 / -30	face mount
10.4"(4:3)	VM10B4 V7	1600	800x600	140 / 160	700:1	LVDS	85 / -30	face mount
10.4"(4:3)	VM10B4 V8	1200	800x600	140 / 160	700:1	LVDS	85 / -30	face mount
10.4"(4:3)	VM10B4 V9	800	800x600	140 / 160	700:1	LVDS	85 / -30	face mount
10.4"(4:3)	VM10B4 VB	1600	800x600	140 / 160	700:1	LVDS	80 / -30	face mount
10.4"(4:3)	VM10B4 VC	1200	800x600	140 / 160	700:1	LVDS	80 / -30	face mount
10.4"(4:3)	VM10B4 VE	1200	800x600	130 / 160	700:1	LVDS	80 / -30	side mount
10.4"(4:3)	VM10B4 VF	1600	800x600	130 / 160	700:1	LVDS	80 / -30	side mount
10.4"(4:3)	VM10B5 V8	2000	800x600	160 / 140	700:1	LVDS	70 / -30
10.4"(4:3)	VM10B5 V9	1000	800x600	160 / 140	700:1	LVDS	70 / -30
10.4"(4:3)	VM10B5 VR	400	800x600	160 / 140	700:1	LVDS	70 / -30
10.4"(4:3)	VM10B6 VR	470	1024x768	178 / 178	3000:1	LVDS	80 / -30
10.4"(4:3)	VM10B6 V3	2000	1024x768	178 / 178	3000:1	LVDS	80 / -30
10.4"(4:3)	VM10B6 V4	1200	1024x768	178 / 178	3000:1	LVDS	80 / -30
10.4"(4:3)	VM10B6 V5	1600	1024x768	178 / 178	3000:1	LVDS	80 / -30
10.4"(4:3)	VM10B6 V7	1500	1024x768	178 / 178	3000:1	LVDS	80 / -30
10.4"(4:3)	VM10B6 VN	500	1024x768	176 / 176	1000:1	LVDS	80 / -30
10.4"(4:3)	VM10B6 VA	1200	1024x768	176 / 176	1000:1	LVDS	80 / -30
10.4"(4:3)	VM10B6 VB	1600	1024x768	176 / 176	1000:1	LVDS	80 / -30
10.4"(4:3)	VM10B9 V1	1000	640x480	160 / 140	700:1	LVDS	85 / -30
10.4"(4:3)	VM10B9 V2	1600	640x480	160 / 140	700:1	LVDS	85 / -30
10.4"(4:3)	VM10B9 V4	1000	640x480	176 / 176	1500:1	TTL	85 / -30
10.4"(4:3)	VM10B9 V5	1600	640x480	176 / 176	1500:1	TTL	85 / -30
12.1"(4:3)	VM12B1 V0	500	800x600	160 / 140	700:1	LVDS	85 / -30
12.1"(4:3)	VM12B1 V2	1000	800x600	160 / 140	700:1	LVDS	85 / -30
12.1"(4:3)	VM12B1 V3	1600	800x600	160 / 140	700:1	LVDS	85 / -30
12.1"(4:3)	VM12B1 V6	2500	800x600	160 / 140	700:1	LVDS	85 / -30
12.1"(4:3)	VM12B1 V4	1000	800x600	178 / 178	1500:1	LVDS	85 / -30
12.1"(4:3)	VM12B1 V5	1600	800x600	178 / 178	1500:1	LVDS	85 / -30
12.1"(4:3)	VM12B1 VR	450	800x600	178 / 178	1500:1	LVDS	85 / -30
12.1"(4:3)	VM12B1 VE	1000	800x600	160 / 140	800:1	LVDS	85 / -30	side mount
12.1"(4:3)	VM12B1 VF	1600	800x600	160 / 140	800:1	LVDS	85 / -30	side mount
12.1"(4:3)	VM12B1 VG	500	800x600	160 / 140	800:1	LVDS	85 / -30	side mount
12.1"(4:3)	VM12B2 V2	1000	1024x768	160 / 160	700:1	LVDS	80 / -30	face mount
12.1"(4:3)	VM12B2 V3	1600	1024x768	160 / 160	700:1	LVDS	80 / -30	face mount
12.1"(4:3)	VM12B4 V7	1600	1024x768	160 / 160	700:1	LVDS	85 / -30	face mount
12.1"(4:3)	VM12B4 V8	1000	1024x768	160 / 160	700:1	LVDS	85 / -30	face mount
12.1"(4:3)	VM12B3 V7	1000	1024x768	178 / 178	1000:1	LVDS	85 / -30	side mount
12.1"(4:3)	VM12B3 V8	1500	1024x768	178 / 178	1000:1	LVDS	85 / -30	side mount
12.1"(4:3)	VM12B3 VR	600	1024x768	178 / 178	1000:1	LVDS	85 / -30	side mount
12.1"(4:3)	VM12B3 VG	1000	1024x768	170 / 170	900:1	LVDS	80 / -30	T:6.5mm
12.1"(4:3)	VM12B3 VH	1500	1024x768	170 / 170	900:1	LVDS	80 / -30	T:6.5mm
12.1"(4:3)	VM12B3 VJ	650	1024x768	170 / 170	900:1	LVDS	80 / -30	T:6.5mm
12.1"(4:3)	VM12B3 VK	1300	1024x768	170 / 170	900:1	LVDS	80 / -30	T:6.5mm
12.1"(16:10)	VM12B5 V6	1000	1280x800	178 / 178	1000:1	LVDS	85 / -30
12.1"(16:10)	VM12B5 V7	2400	1280x800	178 / 178	1000:1	LVDS	85 / -30
12.1"(16:10)	VM12B5 VR	600	1280x800	176 / 176	1000:1	LVDS	80 / -30
12.1"(16:10)	VM12B5 V8	1000	1280x800	176 / 176	1000:1	LVDS	80 / -30
12.1"(16:10)	VM12B5 V9	1500	1280x800	176 / 176	1000:1	LVDS	80 / -30
12.3"EW	VM12S1 V0	750	1920x720	178 / 178	1000:1	LVDS	85 / -30
12.3"EW	VM12S1 V1	1500	1920x720	178 / 178	1000:1	LVDS	85 / -30
15"(4:3)	VM15B6 V0		1024x768	160 / 140	800:1	LVDS	85 / -30
15"(4:3)	VM15B6 V5	1000	1024x768	160 / 140	800:1	LVDS	85 / -30
15"(4:3)	VM15B6 V6	2500	1024x768	160 / 140	800:1	LVDS	85 / -30
15"(4:3)	VM15B56 V7	1500	1024x768	160 / 140	800:1	LVDS	85 / -30
15"(4:3)	VM15B6 VD	1200	1024x768	160 / 160	800:1	LVDS	85 / -30
15"(4:3)	VM15B6 VE	2500	1024x768	160 / 160	800:1	LVDS	85 / -30
15"(4:3)	VM15B6 VF	1500	1024x768	160 / 160	800:1	LVDS	85 / -30
15"(4:3)	VM15BA VN	500	1024*768	176 / 176	2500:1	LVDS	85 / -30
15"(4:3)	VM15BA V6	1000	1024*768	176 / 176	2500:1	LVDS	85 / -30
15"(4:3)	VM15BA V7	1800	1024*768	176 / 176	2500:1	LVDS	85 / -30
15"(4:3)	VM15BA V8	2200	1024*768	176 / 176	2500:1	LVDS	85 / -30
15"(4:3)	VM15BA VA	1000	1024*768	176 / 176	2500:1	LVDS	70 / -30	T:5/8.1 mm
15"(4:3)	VM15BA VB	1500	1024*768	176 / 176	2500:1	LVDS	70 / -30	T:5/8.1 mm
15"(4:3)	VM15BA VC	1000	1024*768	178 / 178	1000:1	LVDS	85 / -30
15"(4:3)	VM15BA VD	1500	1024*768	178 / 178	1000:1	LVDS	85 / -30
15"(4:3)	VM15BA VE	2500	1024*768	178 / 178	1000:1	LVDS	85 / -30
15"(4:3)	VM15BA VG	500	1024*768	178 / 178	1000:1	LVDS	85 / -30
15.4" (16:9)	VM15B8 V0	450	1280x800	160 / 140	700:1	LVDS	80 / -30
15.4" (16:9)	VM15B8 V1	1000	1280x800	160 / 140	700:1	LVDS	80 / -30
15.6" (16:9)	VM15B4 VN	400	1366x768	170 / 160	800:1	LVDS	85 / -30
15.6" (16:9)	VM15B4 V1	1000	1366x768	170 / 160	800:1	LVDS	85 / -30
15.6" (16:9)	VM15B4 V1	1000	1366x768	170 / 160	800:1	LVDS	85 / -30
15.6" (16:9)	VM15B4 V2	1500	1366x768	170 / 160	800:1	LVDS	85 / -30
15.6" (16:9)	VM15B4 V3	500	1366x768	170 / 160	800:1	LVDS	85 / -30
15.6" (16:9)	VM15B4 V4	2500	1366x768	170 / 160	800:1	LVDS	85 / -30
15.6" (16:9)	VM15B4 V4	2500	1366x768	170 / 160	800:1	LVDS	85 / -30
15.6" (16:9)	VM15B1 V0	500	1920x1080	178 / 178	1000:1	eDP	80 / -30	T:4.1/7.5mm
15.6" (16:9)	VM15B1 V1	1200	1920x1080	178 / 178	1000:1	eDP	80 / -30	T:4.1/7.5mm
15.6" (16:9)	VM15B1 V2	1600	1920x1080	178 / 178	1000:1	eDP	80 / -30	T:4.1/7.5mm
15.6" (16:9)	VM15B9 VN	450	1920x1080	178 / 178	1000:1	LVDS	85 / -30
15.6" (16:9)	VM15B9 VH	1000	1920x1080	178 / 178	1000:1	LVDS	85 / -30
15.6" (16:9)	VM15B9 VI	1600	1920x1080	178 / 178	1000:1	LVDS	85 / -30
15.6" (16:9)	VM15B9 VJ	600	1920x1080	178 / 178	1000:1	LVDS	85 / -30
15.6" (16:9)	VM15B9 VK	2000	1920x1080	178 / 178	1000:1	LVDS	85 / -30
17"(5:4)	VM17B4 V1	700	1280x1024	170 / 160	800:1	LVDS	85 / -30
17"(5:4)	VM17B4 V2	850	1280x1024	170 / 160	800:1	LVDS	85 / -30
17"(5:4)	VM17B4 V3	1500	1280x1024	170 / 160	800:1	LVDS	85 / -30
17"(5:4)	VM17B4 V4	1000	1280x1024	170 / 160	800:1	LVDS	85 / -30
17"(5:4)	VM17B4 VA	1000	1280x1024	170 / 160	1000:1	LVDS	80 / -30
17"(5:4)	VM17B4 VB	1500	1280x1024	170 / 160	1000:1	LVDS	80 / -30
17"(5:4)	VM17B4 VC	500	1280x1024	170 / 160	1000:1	LVDS	80 / -30
18.5" (16:9)	VM19B7 VN	350	1920x1080	178 / 178	1000:1	LVDS	80 / -30
18.5" (16:9)	VM19B7 V1	750	1920x1080	178 / 178	1000:1	LVDS	80 / -30
18.5" (16:9)	VM19B7 V2	1000	1920x1080	178 / 178	1000:1	LVDS	80 / -30
18.5" (16:9)	VM19B7 V3	1500	1920x1080	178 / 178	1000:1	LVDS	80 / -30
18.5" (16:9)	VM19B7 V9	2000	1920x1080	178 / 178	1000:1	LVDS	80 / -30
18.5" (16:9)	VM19B7 VR	350	1920x1080	178 / 178	1000:1	LVDS	80 / -30
18.5" (16:9)	VM19B7 VD	750	1920x1080	178 / 178	1000:1	LVDS	80 / -30
18.5" (16:9)	VM19B7 VE	1000	1920x1080	178 / 178	1000:1	LVDS	80 / -30
18.5" (16:9)	VM19B7 VF	1500	1920x1080	178 / 178	1000:1	LVDS	80 / -30
19"(5:4)	VM19B8 V1	900	1280x1024	170 / 160	1000:1	LVDS	85 / -30
19"(5:4)	VM19B8 V2	1200	1280x1024	170 / 160	1000:1	LVDS	85 / -30
19"(5:4)	VM19B8 V3	1600	1280x1024	170 / 160	1000:1	LVDS	85 / -30
21.5"(16:9)	VM22B5 V1	1200	1920x1080	178 / 178	5000:1	LVDS	80 / -30
21.5"(16:9)	VM22B5 V2	600	1920x1080	178 / 178	5000:1	LVDS	80 / -30
21.5"(16:9)	VM22B5 V3	420	1920x1080	178 / 178	5000:1	LVDS	80 / -30
21.5"(16:9)	VM22B6 V1	1000	1920x1080	178 / 178	1000:1	LVDS	80 / -30
21.5"(16:9)	VM22B6 V2	1500	1920x1080	178 / 178	1000:1	LVDS	80 / -30
21.5"(16:9)	VM22B6 V3	2500	1920x1080	178 / 178	1000:1	LVDS	80 / -30
23.8"(16:9)	VM24B3 VG	1200	1920x1080	178 / 178	1000:1	LVDS	70 / -20
23.8"(16:9)	VM24B3 VH	1600	1920x1080	178 / 178	1000:1	LVDS	60 / -20
23.8"(16:9)	VM24B3 VI	2500	1920x1080	178 / 178	1000:1	LVDS	60 / -20
27"(16:9)	VM27B3 V8	1500	1920x1080	178 / 178	1000:1	LVDS	70 / -20
27"(16:9)	VM27B3 V9	2500	1920x1080	178 / 178	1000:1	LVDS	70 / -20
32"(16:9)	VM32B6 V6	3000	1920x1080	178 / 178	1200:1	LVDS	60 / -20
32"(16:9)	VM32B6 V7	2000	1920x1080	178 / 178	1200:1	LVDS	60 / -20
32"(16:9)	VM32B6 V8	1000	1920x1080	178 / 178	1200:1	LVDS	60 / -20
32"(16:9)	VM32B6 V9	700	1920x1080	178 / 178	1200:1	LVDS	60 / -20
43"(16:9)	VM43B1 V1	3000	1920x1080	178 / 178	1200:1	LVDS	60 / -20
43"(16:9)	VM43B1 V2	2000	1920x1080	178 / 178	1200:1	LVDS	60 / -20
43"(16:9)	VM43B1 V3	1000	1920x1080	178 / 178	1200:1	LVDS	60 / -20
43"(16:9)	VM43B1 V4	700	1920x1080	178 / 178	1200:1	LVDS	60 / -20
46"(16:9)	VM46B2 V2	4000	1920x1080	178 / 178	5000:1	LVDS	50 / -10
46"(16:9)	VM46B2 V2	3000	1920x1080	178 / 178	5000:1	LVDS	50 / -10
46"(16:9)	VM46B2 V3	2000	1920x1080	178 / 178	5000:1	LVDS	50 / -10
46"(16:9)	VM46B2 V4	1000	1920x1080	178 / 178	5000:1	LVDS	50 / -10
49"(16:9)	VM49B2 V1	1500	1920x1080	178 / 178	1300:1	LVDS	50 / -10
49"(16:9)	VM49B2 V2	3000	1920x1080	178 / 178	1300:1	LVDS	50 / -10
49"(16:9)	VM49B2 V3	4500	1920x1080	178 / 178	1300:1	LVDS	50 / -10
49"(16:9)	VM49B2 V4	1000	1920x1080	178 / 178	1300:1	LVDS	50 / -10
55"(16:9)	VM55B3 VA	1500	1920x1080	178 / 178	1300:1	LVDS	50 / -10
55"(16:9)	VM55B3 VB	3000	1920x1080	178 / 178	1300:1	LVDS	50 / -10
55"(16:9)	VM55B3 VC	4500	1920x1080	178 / 178	1300:1	LVDS	50 / -10
55"(16:9)	VM55B3 VD	1000	1920x1080	178 / 178	1300:1	LVDS	50 / -10

More information

Industrial Display

High brightness solutions , Industrial LCD , sunlight readable , reliability , long term operation , 24/7 operation

TFT LCD displays are widely used in general industrial fields, some typical applications including:

Outdoor display

High brightness Outdoor LCD solutions , Industrial LCD , sunlight readable , reliability , long term operation , 24/7 operation , direct sunlight , wide operation temperature

Mobility display solution

High brightness Outdoor LCD solutions , sunlight readable , reliability , 24/7 operation , all weather , mobility lcd , thin thickness LCD module

All weather Mobility display solution

Touch panel solutions

High brightness Interactive monitor solutions , touch panel , IR touch , PCAP touch , Projected Capacitive , infrared touch

For LCD-related display applications, touch panel is like a pair of good brothers. In many cases, to...

Control kits

Control kits solutions , LED driver board , AD board , VGA , DVI , DP , LVDS , light sensor , signal convert , mipi , RGB parallel , edp , RS232

LCDs is just like a large river, all different sizes and design have its related different applicati...

Special Module / backlight / optical design

solutions , backlight , LCM , LCD modue , NVIS , optical design , anti-glare , anti-reflection , view angle , spectrum

Although this is not a common application, but for some special projects, system engineers do need s...

Product inquiry

agl lcd , Outdoor LCD direct sunlight , hi-tni , extra wide operation temperature
